Vendor Name:

Beckett

URI Part Number:

1502SS

Vendor Part Number:

1502UR

Description:

Safety Control Switch

Length (In.):

3.00

Width (In.):

1.10

Height (In.):

2.70

Features:

Single pole, double throw, single break snap action switches. Silver contacts. Safe for AC applications. Terminals on switches suitable for 0.020 in. x 0.187 in. female spade connection to your wiring harness if desired.

Shipping Weight (Lbs):

0.16

Weight (Lbs):

0.16

The switch may be wired directly to the system to turn off the air conditioner or furnace equipment, or it can be wired to sound an alarm if the water level becomes too high. Rated 125V, 5A, 1/10 HP. Wired normally closed.

• Single pole, double throw, single break snap action switches
• Prewired—leads 17" + 1/2"
• Safe for either AC or DC (low voltage) applications
